Description
This is an improved Honda Honda TID12-20 ECU Replacement (x2).
What is better compared to the original unit:
– increased protection against over-voltage (such as a defective voltage regulator/rectifier, bad battery).
– higher resistance against a defective ignition coil and reverse battery connection .
– acceleration correction: when the RPM increases the ignition delay changes (in proportion) resulting in a smoother acceleration.
– digital technique: therefor the unit is more accurate and less sensitive to temperature changes.
– optimized ignition curve/map to improve engine performance resulting in more power.
– spark power control: the unit will change the output to the ignition coil when the battery voltage changes in order to keep the spark power the same.
– start mode: during engine start there’s a start delay and the unit will give more current to the ignition coil for a faster start.
This ECU is used in the models below.
Please note that this (small) list is for reference use only.
We do our best to keep this up-to-date:
Honda VT700 Shadow CDI
Honda VT700C Shadow CDI
Honda VT700 C RC14 CDI
Honda VT750 Shadow CDI
Honda VT750C Shadow CDI
Honda VT750C RD14 CDI
1983 1984 1985 1986 1987
OEM numbers:
TID12-11
TID12-11A
TID12-20
ME9
IC IGNITOR
Hitachi, Ltd Tokyo Japan
Other names:
EC Ignitor, brain, ignition module
CDI, ECU, ECM computer, Black Box, Ignitor
ignition control module, spark box
Ignition Spark Control Module
CDI Ignition
Model: CARI-HO-VT700-VT750-ME9-2 CDI TID12-11(A) 2x
000.350.000 S120 45
